TeleGiga H1 Keychain Beacon

TG-H1 Keychain Beacon

H1 Beacon is a portable keychain beacon tag with NORDIC ® nRF52 series of extremely-low power ARM ® chipsets. It has the shape of a compact case, waterproof design, reliable hardware, powerful firmware, and outer push button. It has been designed for promotional marketing and service focused on the indoor venue. This beacon is suitable for Apple and Android devices. H1 Beacon is portable with the keychain.

Get A Quote
Compact Keychain Design
Lightweight 32.5mm form factor with flexible mounting—hang, neck chain, or sticker.
Multi-Protocol & OTA Ready
Supports iBeacon, Eddystone (UID/URL/TLM) with GATT service and OTA firmware updates.
Replaceable CR2032 Battery
240mAh cell delivers up to 1.5 years of runtime with easy replacement.
Durable & Certified
IP65 waterproof, ABS+PC+TPU build, and certified for FCC, CE, RoHS, REACH.
Specifications
Feature Details
Model TG H1 Keychain Beacon
Size (H×W×L) 32.5 × 32.5 × 7.0 mm
Battery Model CR2032
Battery Capacity 240mAh
Default Battery Life 1.5 years
Battery Replaceable Yes
Range Up to 150 meters (open area, no obstacles)
Waterproof IP65
Protocols iBeacon & Eddystone: UID, URL, TLM; GATT Service
Firmware Updating OTA (Over-the-Air)
Installation Keychain, Hang, Neck chain, Sticker
Sensor 3-axis accelerometer sensor, Buzzer (optional)
Material ABS + PC & TPU
Certification FCC (USA), CE-RED, CE-LVD, CE-EMC, REACH, RoHS (Europe); Custom options available
