TeleGiga M3 mini Asset Tracking Tag

TG-M3 mini Asset Tracking Tag

M3 mini is an advanced Bluetooth asset tracking tag, specifically engineered for industrial applications. With its superior design, the M3 mini offers exceptional structural and installation benefits, making it an ideal solution for a wide range of industrial assets.  Equipped with a large 2600mAh battery, the M3 mini has an ultra-long service life of over 8 years, and its waterproof and anti-collision capabilities allow it to withstand harsh environments. Whether in manufacturing, construction, or warehouses, the M3 mini is the ultimate choice for reliable and precise tracking.

Get A Quote
Extended BLE Range
BLE 5.0 with up to 350m transmission using Coded PHY.
Rugged & Waterproof
IP67 rated with IK08 shock resistance for harsh environments.
Ultra-Long Battery Life
Replaceable 2600mAh battery lasts up to 8+ years.
Multi-Mount & Sensor Ready
Supports screw, zip tie, sticker, and optional magnetic mount with accelerometer & magnetic switch.
Specifications
Feature Details
Model TG M3 Mini Asset Tracking Tag
Connectivity BLE 5.0
Dimensions 94.6 × 51.7 × 22.8 mm
Color Gray
Material PC + ASA
IP Rating IP67
Shock Resistance IK08
Sensor Accelerometer sensor, Magnetic switch (optional)
Battery Capacity 2600mAh | Replaceable battery
Battery Lifespan 8+ years (1M PHY), 3+ years (Coded PHY - optional)
Operating Temperature -20°C to 60°C
Transmission Range Up to 160m (1M PHY), Up to 350m (Coded PHY)
Installation Screw, Sticker, Zip Tie, Magnetic mounting (optional)
Certification FCC, CE, RoHS, REACH
